Bharat Heavy Electricals Ltd has successfully manufactured and conducted the short-circuit test of India’s highest rating auto transformer at National High Power Test Laboratory (NHPTL) at Bina in Madhya Pradesh.
Significantly, this is a new benchmark in the global transformer industry. Short circuit test is the most stringent, special type test for power transformers which is conducted to prove the adequacy for power transformers to withstand abnormal conditions of short circuit to ensure reliability during their operations in the field.
Incidentally, this is BHEL’s twenty-first 400kV-class transformer, which has successfully passed the short circuit test, indicating the company’s prowess in the sector.
This 500 MVA 400/220/33kV auto transformer has been designed and manufactured at BHEL’s Bhopal plant for UP Power Transmission Corporation Ltd. These high rating transformers play a crucial role in bulk power transmission to load centres and bigger cities.
BHEL is the largest manufacturer of power transformers in India and a pioneer in the indigenous development of higher rating and specialised transformers, with voltage levels going up to 1,200kV class.
BHEL’s transformer plant at Bhopal has a world-class, state-of-the-art facility, which is at par with its global peers and is fully equipped to meet the expectations of utilities in India as well as abroad in the entire range of power transformers and shunt reactors.
All photographs (source: NHPTL) relate to the actual testing of BHEL’s 400kV auto transformer at NHPTL’s Bina laboratory in Madhya Pradesh. Photographs added on December 2, 2020.
